Sudong technicians discuss the installation of chamber filter press with you

Recently, the XAYZB80/1070-U reinforced polypropylene plate chamber filter press ordered by a Shaanxi customer arrived at the customer's site smoothly, and Sudong quickly started the installation work. Let's follow the technicians to see the installation skills of the chamber filter press.

1. Lifting of the whole machine

When lifting the unit, remove the hydraulic station, then remove all movable filter plates (be careful not to damage the sealing surface of the filter plates when removing the filter plates) to reduce the lifting weight. The lifting rope should be hooked on the exposed part of the two ends of the beam for lifting. The center of gravity must be found during lifting, and the steel rope should be selected reasonably. The contact parts between the steel rope and the components should be padded with soft materials to avoid damaging the components. After the frame is installed, put the filter plates back into the frame in the original order. Small machines can be lifted as a whole.

2. Installation of the machine

(1) The machine should generally be installed on a building about 2 to 2.5 meters above the ground to facilitate the unloading and transportation of the filter cake. It must not be installed in open places.

(2) Before installation, build the foundation and set the reserved holes for the anchor bolts for secondary grouting.

(3) During installation, the two beams of the machine need to be aligned in the same plane with a level. At the same time, to facilitate the flow of filtrate during operation, the outlet end can be lowered by 30 to 40 mm from the other end.

(4) During installation, the two machine feet of the machine are fixed with anchor bolts. The foundation should be grouted twice.

(5) The installation site should not be too far from the material processing site. The base of the whole machine should be a certain distance higher than the foundation surface so that a liquid collection tray can be placed under the machine.

(6) The electrical control cabinet should be installed in a place where it is not exposed to corrosion sources, with an ambient temperature of 0~55℃, a relative humidity of 5~95%, and no condensation. Avoid damage to electrical components and affect normal operation.

(7) The selection of feed flow should be based on the limited pressure and flow, and a return pipe and a pressure gauge should be installed on the feed pipe to ensure that the machine is within a safe working pressure when working. If the machine model is washable, the selection of the washing pump should be compatible with the feed pump, and the pressure of the washing pump should be slightly higher than that of the feed pump.

(8) For the installation of the pipeline system, users can install it according to the pipeline layout diagram and the actual situation on site but must ensure the convenience of installation, use, and maintenance. The pipeline should be as short as possible and reduce turns.

(9) The installation location of the hydraulic station can be determined by the user. If changes are required, the oil pipes shall be configured by the user.

(10) Connect the power cord to the electric control cabinet according to the terminal wiring diagram of the electric control cabinet, and check to ensure that there are no errors.
